mcp使用介绍

本文详细介绍了MCP(Micro Cloud Platform)服务的使用方法和调用规范。MCP是一个轻量级微服务云平台,提供了丰富的API接口和服务集成能力。通过本指南,您将了解MCP的核心功能、接口规范、认证机制、调用示例以及最佳实践,帮助您在项目中高效地集成和使用MCP服务。

🚀 MCP服务概述

MCP(Micro Cloud Platform)是一个现代化的微服务云平台,专为企业级应用设计,提供了丰富的服务集成能力和API接口。

核心特性

  • 服务注册与发现:自动化的服务注册和发现机制
  • 负载均衡:智能的请求分发策略
  • 服务网关:统一的API入口和路由管理
  • 服务编排:灵活的服务组合和流程编排
  • 集群部署:支持多节点集群部署
  • 故障转移:自动检测故障并进行服务切换
  • 熔断机制:防止级联故障的智能熔断
  • 限流保护:基于QPS的请求限流策略
  • 多租户隔离:严格的租户资源隔离
  • 身份认证:支持多种认证方式(Token、OAuth2.0等)
  • 权限控制:细粒度的API访问控制
  • 数据加密:传输和存储数据加密
  • 分布式追踪:请求全链路追踪
  • 性能监控:实时服务性能监控
  • 日志管理:集中式日志收集和分析
  • 告警机制:异常情况实时告警

技术架构

点击查看MCP架构图
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
+----------------------------------+
| 客户端应用 |
+----------------------------------+
|
| HTTPS

+----------------------------------+
| API网关层 |
| +----------+ +----------+ |
| | 认证授权 | | 流量控制 | |
| +----------+ +----------+ |
+----------------------------------+
|
| 内部调用

+----------------------------------+
| 服务治理层 |
| +----------+ +----------+ |
| | 服务注册 | | 服务发现 | |
| +----------+ +----------+ |
| +----------+ +----------+ |
| | 负载均衡 | | 熔断降级 | |
| +----------+ +----------+ |
+----------------------------------+
|
| 服务调用

+----------------------------------+
| 微服务集群 |
| +----------+ +----------+ |
| | 业务服务A| | 业务服务B| |
| +----------+ +----------+ |
| +----------+ +----------+ |
| | 业务服务C| | 业务服务D| |
| +----------+ +----------+ |
+----------------------------------+
|
| 数据访问

+----------------------------------+
| 数据存储层 |
| +----------+ +----------+ |
| | MySQL | | Redis | |
| +----------+ +----------+ |
| +----------+ +----------+ |
| | MongoDB | | Kafka | |
| +----------+ +----------+ |
+----------------------------------+

💻 安装与配置

环境要求

在安装MCP服务之前,请确保您的环境满足以下要求:

  • 操作系统:Linux(推荐Ubuntu 18.04+/CentOS 7+)、Windows Server 2016+
  • Docker:18.09.0+
  • Kubernetes:1.16+(可选,用于集群部署)
  • 内存:最小4GB,推荐8GB+
  • CPU:最小2核,推荐4核+
  • 存储:最小20GB,推荐50GB+
  • 网络:稳定的网络连接,开放相关端口

安装步骤

安装流程

  1. 下载安装包
1
2
3
4
5
6
# 从官方仓库下载最新版本
wget https://github.com/mcp-project/mcp/releases/download/v1.5.0/mcp-1.5.0.tar.gz

# 解压安装包
tar -zxvf mcp-1.5.0.tar.gz
cd mcp-1.5.0
  1. 配置环境
1
2
3
4
5
# 复制配置文件模板
cp config/mcp.yaml.example config/mcp.yaml

# 编辑配置文件
vim config/mcp.yaml

配置文件示例:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
# MCP核心配置
server:
port: 8080
context-path: /api

# 数据库配置
database:
type: mysql
host: localhost
port: 3306
username: mcp_user
password: mcp_password
database: mcp

# 缓存配置
cache:
type: redis
host: localhost
port: 6379
password: redis_password

# 认证配置
auth:
jwt:
secret: your_jwt_secret_key
expiration: 86400 # 24小时

# 日志配置
logging:
level: INFO
path: /var/log/mcp

  1. 启动服务
1
2
3
4
5
# 使用Docker Compose启动
docker-compose up -d

# 或使用脚本启动
./bin/startup.sh

启动成功后,可以通过以下命令检查服务状态:

1
./bin/status.sh

  1. 验证安装
1
2
3
4
5
# 测试API是否可访问
curl http://localhost:8080/api/v1/health

# 预期输出
{"status":"UP","version":"1.5.0","timestamp":"2023-07-15T10:30:00Z"}

Docker部署

docker-compose.yml
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
version: '3.7'

services:
mcp-server:
image: mcp/server:1.5.0
container_name: mcp-server
restart: always
ports:
- "8080:8080"
environment:
- SPRING_PROFILES_ACTIVE=prod
- DB_HOST=mysql
- DB_PORT=3306
- DB_NAME=mcp
- DB_USER=mcp_user
- DB_PASSWORD=mcp_password
- REDIS_HOST=redis
- REDIS_PORT=6379
- REDIS_PASSWORD=redis_password
volumes:
- ./config:/app/config
- ./logs:/app/logs
depends_on:
- mysql
- redis

mysql:
image: mysql:8.0
container_name: mcp-mysql
restart: always
ports:
- "3306:3306"
environment:
- MYSQL_ROOT_PASSWORD=root_password
- MYSQL_DATABASE=mcp
- MYSQL_USER=mcp_user
- MYSQL_PASSWORD=mcp_password
volumes:
- mysql-data:/var/lib/mysql
- ./init-scripts:/docker-entrypoint-initdb.d

redis:
image: redis:6.2
container_name: mcp-redis
restart: always
ports:
- "6379:6379"
command: redis-server --requirepass redis_password
volumes:
- redis-data:/data

volumes:
mysql-data:
redis-data:

🔑 认证与授权

MCP服务采用多种认证机制,确保API调用的安全性。

认证方式

最简单的认证方式,适用于服务器端调用:

1
2
3
GET /api/v1/resources HTTP/1.1
Host: mcp.example.com
X-API-Key: your_api_key_here

获取API Key的方式:

  1. 登录MCP管理控制台
  2. 导航至「安全」>「API密钥」
  3. 点击「创建密钥」按钮
  4. 设置密钥名称和权限范围
  5. 生成并保存API Key(注意:密钥只显示一次)

基于Token的认证方式,适用于用户会话:

1
2
3
GET /api/v1/resources HTTP/1.1
Host: mcp.example.com
Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...

获取JWT Token的流程:

  1. 调用登录接口获取Token

    1
    2
    3
    4
    5
    6
    7
    8
    POST /api/v1/auth/login HTTP/1.1
    Host: mcp.example.com
    Content-Type: application/json

    {
    "username": "your_username",
    "password": "your_password"
    }
  2. 从响应中获取Token

    1
    2
    3
    4
    {
    "token": "eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...",
    "expires_in": 86400
    }

适用于第三方应用授权:

  1. 获取授权码

    1
    GET https://mcp.example.com/api/v1/oauth/authorize?client_id=your_client_id&redirect_uri=your_redirect_uri&response_type=code&scope=read
  2. 使用授权码获取访问令牌

    1
    2
    3
    4
    5
    POST /api/v1/oauth/token HTTP/1.1
    Host: mcp.example.com
    Content-Type: application/x-www-form-urlencoded

    client_id=your_client_id&client_secret=your_client_secret&grant_type=authorization_code&code=authorization_code&redirect_uri=your_redirect_uri
  3. 使用访问令牌调用API

    1
    2
    3
    GET /api/v1/resources HTTP/1.1
    Host: mcp.example.com
    Authorization: Bearer access_token_here

权限控制

MCP采用基于角色(RBAC)的权限控制模型:

1
2
3
4
5
6
7
8
graph TD
A[用户] -->|属于| B[角色]
B -->|拥有| C[权限]
C -->|控制| D[资源访问]

E[管理员角色] -->|拥有| F[所有权限]
G[操作员角色] -->|拥有| H[读写权限]
I[访客角色] -->|拥有| J[只读权限]

📡 API接口规范

接口版本控制

MCP API采用URI路径方式进行版本控制:

  • v1版本/api/v1/resources
  • v2版本/api/v2/resources

当API发生不兼容变更时,会增加新的版本号。我们承诺同一版本的API在其生命周期内保持向后兼容。

请求格式

标准请求格式
1
2
3
4
5
6
7
8
9
10
11
12
13
14
POST /api/v1/resources HTTP/1.1
Host: mcp.example.com
Authorization: Bearer your_token_here
Content-Type: application/json
X-Request-ID: 550e8400-e29b-41d4-a716-446655440000

{
"name": "resource_name",
"type": "resource_type",
"properties": {
"key1": "value1",
"key2": "value2"
}
}

响应格式

所有API响应均使用统一的JSON格式:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
{
"code": 200,
"message": "操作成功",
"data": {
"id": "550e8400-e29b-41d4-a716-446655440000",
"name": "resource_name",
"type": "resource_type",
"properties": {
"key1": "value1",
"key2": "value2"
},
"created_at": "2023-07-15T10:30:00Z",
"updated_at": "2023-07-15T10:30:00Z"
},
"request_id": "550e8400-e29b-41d4-a716-446655440000"
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
{
"code": 400,
"message": "请求参数错误",
"errors": [
{
"field": "name",
"message": "名称不能为空"
},
{
"field": "type",
"message": "类型必须是预定义类型之一"
}
],
"request_id": "550e8400-e29b-41d4-a716-446655440000"
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
{
"code": 200,
"message": "操作成功",
"data": {
"items": [
{
"id": "550e8400-e29b-41d4-a716-446655440000",
"name": "resource_name_1",
"type": "resource_type"
},
{
"id": "550e8400-e29b-41d4-a716-446655440001",
"name": "resource_name_2",
"type": "resource_type"
}
],
"pagination": {
"page": 1,
"page_size": 10,
"total": 42,
"total_pages": 5
}
},
"request_id": "550e8400-e29b-41d4-a716-446655440000"
}

错误码说明

点击查看错误码列表
错误码描述处理建议
200成功请求成功处理
400请求参数错误检查请求参数是否符合要求
401未授权检查认证信息是否正确
403权限不足确认是否有足够权限访问资源
404资源不存在检查请求的资源ID是否正确
409资源冲突资源已存在或状态冲突
429请求过于频繁降低请求频率,遵循限流规则
500服务器内部错误联系技术支持
503服务不可用服务可能正在维护,稍后重试
10001用户名或密码错误检查登录凭证
10002账户已锁定联系管理员解锁账户
10003令牌已过期重新获取认证令牌
20001资源配额不足升级服务等级或释放未使用资源
20002操作不支持检查资源当前状态是否支持该操作
30001数据库操作失败检查数据完整性或联系技术支持

📊 服务调用示例

客户端SDK

MCP提供多种语言的SDK,简化API调用:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
// 添加依赖
// Maven
<dependency>
<groupId>com.mcp</groupId>
<artifactId>mcp-client</artifactId>
<version>1.5.0</version>
</dependency>

// 代码示例
import com.mcp.client.MCPClient;
import com.mcp.client.auth.ApiKeyAuth;
import com.mcp.client.model.Resource;

public class MCPExample {
public static void main(String[] args) {
// 初始化客户端
MCPClient client = MCPClient.builder()
.endpoint("https://mcp.example.com")
.auth(new ApiKeyAuth("your_api_key"))
.build();

// 创建资源
Resource resource = new Resource();
resource.setName("test-resource");
resource.setType("compute");

// 调用API
try {
Resource created = client.getResourceService().createResource(resource);
System.out.println("Created resource ID: " + created.getId());
} catch (MCPException e) {
System.err.println("Error: " + e.getMessage());
}
}
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
# 安装依赖
# pip install mcp-client

# 代码示例
from mcp_client import MCPClient
from mcp_client.auth import JWTAuth
from mcp_client.exceptions import MCPError

# 初始化客户端
client = MCPClient(
endpoint="https://mcp.example.com",
auth=JWTAuth(token="your_jwt_token")
)

# 调用API
try:
# 获取资源列表
response = client.resources.list(page=1, page_size=10)

# 打印结果
print(f"Total resources: {response.pagination.total}")
for item in response.items:
print(f"Resource: {item.name} (ID: {item.id})")

# 创建新资源
new_resource = {
"name": "test-resource",
"type": "storage",
"properties": {
"size": "100GB",
"zone": "us-east-1"
}
}

created = client.resources.create(new_resource)
print(f"Created resource with ID: {created.id}")

except MCPError as e:
print(f"Error: {e.code} - {e.message}")
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
// 安装依赖
// npm install mcp-client

// 代码示例
const { MCPClient } = require('mcp-client');
const { OAuth2Auth } = require('mcp-client/auth');

// 初始化客户端
const client = new MCPClient({
endpoint: 'https://mcp.example.com',
auth: new OAuth2Auth({
accessToken: 'your_access_token'
}),
timeout: 30000 // 30秒超时
});

// 异步调用示例
async function mcpExample() {
try {
// 查询资源
const { data } = await client.resources.query({
type: 'compute',
status: 'running',
limit: 5
});

console.log(`Found ${data.pagination.total} resources`);

// 获取单个资源详情
if (data.items.length > 0) {
const resourceId = data.items[0].id;
const resourceDetail = await client.resources.get(resourceId);
console.log('Resource details:', resourceDetail.data);

// 更新资源
const updated = await client.resources.update(resourceId, {
properties: {
tags: ['production', 'web-tier']
}
});
console.log('Updated resource:', updated.data);
}
} catch (error) {
console.error('API Error:', error.message);
if (error.response) {
console.error('Error details:', error.response.data);
}
}
}

mcpExample();
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
// 安装依赖
// go get github.com/mcp/mcp-client-go

// 代码示例
package main

import (
"context"
"fmt"
"log"

"github.com/mcp/mcp-client-go"
"github.com/mcp/mcp-client-go/auth"
)

func main() {
// 初始化客户端
client, err := mcp.NewClient(
mcp.WithEndpoint("https://mcp.example.com"),
mcp.WithAuth(auth.NewAPIKey("your_api_key")),
)
if err != nil {
log.Fatalf("Failed to create client: %v", err)
}

// 创建上下文
ctx := context.Background()

// 列出资源
resources, err := client.Resources.List(ctx, &mcp.ResourceListParams{
Page: 1,
PageSize: 10,
Type: "database",
})
if err != nil {
log.Fatalf("Failed to list resources: %v", err)
}

fmt.Printf("Found %d resources\n", resources.Pagination.Total)

// 创建资源
newResource := &mcp.ResourceCreateParams{
Name: "test-db",
Type: "database",
Properties: map[string]interface{}{
"engine": "mysql",
"version": "8.0",
"size": "medium",
},
}

created, err := client.Resources.Create(ctx, newResource)
if err != nil {
log.Fatalf("Failed to create resource: %v", err)
}

fmt.Printf("Created resource with ID: %s\n", created.ID)

// 获取资源详情
detail, err := client.Resources.Get(ctx, created.ID)
if err != nil {
log.Fatalf("Failed to get resource: %v", err)
}

fmt.Printf("Resource details: %+v\n", detail)
}

REST API调用

不使用SDK,直接调用REST API的示例:

curl示例
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
# 获取认证Token
curl -X POST https://mcp.example.com/api/v1/auth/login \
-H "Content-Type: application/json" \
-d '{"username":"admin","password":"password123"}'

# 响应
# {"code":200,"message":"登录成功","data":{"token":"eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...","expires_in":86400},"request_id":"550e8400-e29b-41d4-a716-446655440000"}

# 使用Token创建资源
curl -X POST https://mcp.example.com/api/v1/resources \
-H "Content-Type: application/json" \
-H "Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9..." \
-d '{
"name": "web-server-01",
"type": "compute",
"properties": {
"cpu": 2,
"memory": "4GB",
"disk": "100GB",
"image": "ubuntu-20.04"
}
}'

# 查询资源列表
curl -X GET https://mcp.example.com/api/v1/resources?type=compute&status=running \
-H "Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9..."

# 获取单个资源详情
curl -X GET https://mcp.example.com/api/v1/resources/550e8400-e29b-41d4-a716-446655440000 \
-H "Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9..."

# 更新资源
curl -X PUT https://mcp.example.com/api/v1/resources/550e8400-e29b-41d4-a716-446655440000 \
-H "Content-Type: application/json" \
-H "Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9..." \
-d '{
"properties": {
"tags": ["production", "web-tier"]
}
}'

# 删除资源
curl -X DELETE https://mcp.example.com/api/v1/resources/550e8400-e29b-41d4-a716-446655440000 \
-H "Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9..."

WebSocket接口

MCP还提供WebSocket接口,用于实时数据推送和事件通知:

WebSocket连接示例
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
// 建立WebSocket连接
const token = 'eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...';
const ws = new WebSocket(`wss://mcp.example.com/api/v1/ws?token=${token}`);

// 连接建立时的处理
ws.onopen = () => {
console.log('WebSocket连接已建立');

// 订阅资源变更事件
ws.send(JSON.stringify({
action: 'subscribe',
channel: 'resource.events',
filter: {
resource_type: 'compute',
event_types: ['created', 'updated', 'deleted']
}
}));
};

// 接收消息
ws.onmessage = (event) => {
const message = JSON.parse(event.data);
console.log('收到消息:', message);

// 处理不同类型的事件
switch (message.event_type) {
case 'resource.created':
console.log(`新资源已创建: ${message.data.name} (ID: ${message.data.id})`);
break;
case 'resource.updated':
console.log(`资源已更新: ${message.data.id}`);
break;
case 'resource.deleted':
console.log(`资源已删除: ${message.data.id}`);
break;
case 'system.notification':
console.log(`系统通知: ${message.data.message}`);
break;
}
};

// 错误处理
ws.onerror = (error) => {
console.error('WebSocket错误:', error);
};

// 连接关闭
ws.onclose = (event) => {
console.log(`WebSocket连接已关闭,代码: ${event.code},原因: ${event.reason}`);

// 可以在这里实现重连逻辑
if (event.code !== 1000) { // 非正常关闭
console.log('尝试重新连接...');
// 重连逻辑
}
};

// 主动关闭连接
// ws.close();

批量操作

MCP支持批量操作,提高API调用效率:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
POST /api/v1/resources/batch HTTP/1.1
Host: mcp.example.com
Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...
Content-Type: application/json

{
"items": [
{
"name": "web-server-01",
"type": "compute",
"properties": {
"cpu": 2,
"memory": "4GB"
}
},
{
"name": "web-server-02",
"type": "compute",
"properties": {
"cpu": 2,
"memory": "4GB"
}
},
{
"name": "db-server-01",
"type": "database",
"properties": {
"engine": "mysql",
"version": "8.0"
}
}
]
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
PUT /api/v1/resources/batch HTTP/1.1
Host: mcp.example.com
Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...
Content-Type: application/json

{
"items": [
{
"id": "550e8400-e29b-41d4-a716-446655440000",
"properties": {
"tags": ["production"]
}
},
{
"id": "550e8400-e29b-41d4-a716-446655440001",
"properties": {
"tags": ["staging"]
}
}
]
}
1
2
3
4
5
6
7
8
9
10
11
12
DELETE /api/v1/resources/batch HTTP/1.1
Host: mcp.example.com
Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...
Content-Type: application/json

{
"ids": [
"550e8400-e29b-41d4-a716-446655440000",
"550e8400-e29b-41d4-a716-446655440001",
"550e8400-e29b-41d4-a716-446655440002"
]
}
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
POST /api/v1/resources/query HTTP/1.1
Host: mcp.example.com
Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...
Content-Type: application/json

{
"filters": [
{
"field": "type",
"operator": "eq",
"value": "compute"
},
{
"field": "properties.status",
"operator": "in",
"value": ["running", "stopped"]
},
{
"field": "created_at",
"operator": "gte",
"value": "2023-01-01T00:00:00Z"
}
],
"sort": {
"field": "created_at",
"order": "desc"
},
"page": 1,
"page_size": 20
}

🛠️ 高级功能

资源监控

MCP提供实时资源监控功能,帮助您了解资源的运行状态:

监控数据可通过以下方式获取:

  1. REST API:定期轮询获取监控数据
  2. WebSocket:实时推送监控数据
  3. Prometheus集成:通过标准的Prometheus接口导出监控指标
1
2
3
4
5
6
7
8
9
10
11
gantt
title 资源监控数据保留策略
dateFormat YYYY-MM-DD
section 高精度数据
1分钟粒度 :a1, 2023-07-01, 7d
section 中精度数据
5分钟粒度 :a2, 2023-07-01, 30d
section 低精度数据
1小时粒度 :a3, 2023-07-01, 90d
section 归档数据
1天粒度 :a4, 2023-07-01, 365d

事件通知

MCP支持多种事件通知方式,确保您及时了解系统中的重要变更:

配置Webhook接收事件通知:

1
2
3
4
5
6
7
8
9
10
11
12
POST /api/v1/webhooks HTTP/1.1
Host: mcp.example.com
Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...
Content-Type: application/json

{
"name": "resource-events",
"url": "https://your-server.com/webhook/mcp-events",
"secret": "your_webhook_secret",
"events": ["resource.created", "resource.deleted", "alert.*"],
"status": "active"
}

Webhook接收到的事件格式:

1
2
3
4
5
6
7
8
9
10
11
{
"id": "evt_550e8400e29b41d4a716446655440000",
"event_type": "resource.created",
"created_at": "2023-07-15T10:30:00Z",
"data": {
"id": "550e8400-e29b-41d4-a716-446655440000",
"name": "web-server-01",
"type": "compute"
},
"signature": "sha256=..."
}

配置邮件通知:

1
2
3
4
5
6
7
8
9
10
11
POST /api/v1/notifications/email HTTP/1.1
Host: mcp.example.com
Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...
Content-Type: application/json

{
"name": "critical-alerts",
"recipients": ["admin@example.com", "ops@example.com"],
"events": ["alert.critical", "system.maintenance"],
"status": "active"
}

配置短信通知:

1
2
3
4
5
6
7
8
9
10
11
POST /api/v1/notifications/sms HTTP/1.1
Host: mcp.example.com
Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...
Content-Type: application/json

{
"name": "emergency-alerts",
"recipients": ["+8613800138000", "+8613900139000"],
"events": ["alert.critical", "system.outage"],
"status": "active"
}

定时任务

MCP支持定时任务功能,可以按计划执行特定操作:

创建定时任务
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
POST /api/v1/schedules HTTP/1.1
Host: mcp.example.com
Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9...
Content-Type: application/json

{
"name": "daily-backup",
"description": "每日数据库备份",
"schedule": "0 0 * * *", // Cron表达式:每天0点执行
"action": {
"type": "api_call",
"method": "POST",
"path": "/api/v1/databases/{database_id}/backups",
"path_params": {
"database_id": "550e8400-e29b-41d4-a716-446655440000"
},
"body": {
"type": "full",
"retention_days": 7
}
},
"status": "active"
}

🔍 故障排查与错误处理

常见问题解决

认证相关问题

1. Token无效或过期

症状:API请求返回401错误,消息为”令牌已过期”或”无效的令牌”

解决方案

  • 检查Token是否过期(JWT Token可以在jwt.io解码查看)
  • 重新获取新的Token
  • 确保Token正确添加到请求头中(格式为Authorization: Bearer your_token

2. 权限不足

症状:API请求返回403错误,消息为”权限不足”

解决方案

  • 检查用户角色是否有足够权限
  • 联系管理员授予必要权限
  • 使用具有更高权限的账户
连接问题

1. 无法连接到MCP服务

症状:连接超时或拒绝

解决方案

  • 检查网络连接是否正常
  • 确认MCP服务是否正常运行
  • 检查防火墙设置,确保相关端口已开放
  • 验证服务地址是否正确

2. SSL/TLS证书问题

症状:SSL握手失败或证书验证错误

解决方案

  • 确保客户端信任服务器证书
  • 检查证书是否过期
  • 对于开发环境,可以配置跳过证书验证(生产环境不推荐)
性能问题

1. 请求响应缓慢

症状:API请求响应时间异常长

解决方案

  • 检查网络延迟
  • 优化请求参数,减少返回数据量
  • 使用批量API减少请求次数
  • 检查MCP服务器负载情况

2. 请求被限流

症状:收到429错误,消息为”请求过于频繁”

解决方案

  • 降低请求频率
  • 实现指数退避重试策略
  • 联系管理员调整限流配置
  • 优化代码,减少不必要的API调用

日志收集与分析

MCP提供全面的日志收集和分析功能,帮助排查问题:

日志级别从低到高依次为:DEBUG < INFO < WARN < ERROR < FATAL

建议的日志级别设置:

  • 开发环境:DEBUG或INFO
  • 测试环境:INFO
  • 生产环境:WARN或ERROR
获取系统日志
1
2
3
4
5
6
7
8
9
10
11
# 获取最近的系统日志
curl -X GET https://mcp.example.com/api/v1/logs?level=ERROR&limit=100 \
-H "Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9..."

# 获取特定时间范围的日志
curl -X GET "https://mcp.example.com/api/v1/logs?start_time=2023-07-14T00:00:00Z&end_time=2023-07-15T23:59:59Z&level=WARN" \
-H "Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9..."

# 获取特定资源的操作日志
curl -X GET "https://mcp.example.com/api/v1/resources/550e8400-e29b-41d4-a716-446655440000/logs" \
-H "Authorization: Bearer eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9..."

💯 最佳实践

性能优化

安全建议

保护您的MCP服务和API调用安全:

定期轮换API密钥和访问令牌

使用HTTPS加密所有API通信

实施最小权限原则,只授予必要的权限

启用审计日志,记录所有关键操作

实施IP白名单,限制API访问来源

设置请求超时,防止长时间挂起

加密存储敏感配置信息

定期审查权限和访问控制设置

错误处理策略

在客户端代码中实现健壮的错误处理:

错误处理最佳实践

区分临时性错误和永久性错误

  • 临时性错误(如429、503):实现重试机制
  • 永久性错误(如400、404):修复请求或报告错误
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
async function callApiWithRetry(apiFunc, maxRetries = 3, initialDelay = 1000) {
let retries = 0;

while (true) {
try {
return await apiFunc();
} catch (error) {
// 判断是否是临时性错误
const isTransient = error.status === 429 || error.status === 503;

// 如果不是临时性错误,或者已达到最大重试次数,则抛出错误
if (!isTransient || retries >= maxRetries) {
throw error;
}

// 计算退避延迟(指数退避)
const delay = initialDelay * Math.pow(2, retries);
console.log(`请求失败,${delay}ms后重试(${retries + 1}/${maxRetries})`);

// 等待后重试
await new Promise(resolve => setTimeout(resolve, delay));
retries++;
}
}
}

实现优雅降级

当核心服务不可用时,提供备选方案:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
async function getResourceData(resourceId) {
try {
// 尝试从API获取最新数据
return await api.resources.get(resourceId);
} catch (error) {
console.error('API请求失败:', error);

// 尝试从本地缓存获取数据
const cachedData = localStorage.getItem(`resource_${resourceId}`);
if (cachedData) {
console.log('使用缓存数据');
return JSON.parse(cachedData);
}

// 如果缓存也没有,则使用默认值
console.log('使用默认数据');
return {
id: resourceId,
name: 'Unknown Resource',
status: 'unknown',
// 其他默认属性
};
}
}

提供有用的错误信息

确保错误信息对用户有帮助:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
function handleApiError(error) {
// 提取错误详情
const status = error.response?.status;
const errorCode = error.response?.data?.code;
const message = error.response?.data?.message || error.message;
const details = error.response?.data?.errors;

// 根据错误类型提供具体指导
switch (status) {
case 400:
return `请求参数错误: ${message}${formatValidationErrors(details)}`;
case 401:
return '您的登录已过期,请重新登录';
case 403:
return '您没有权限执行此操作';
case 404:
return '请求的资源不存在';
case 429:
return '请求过于频繁,请稍后再试';
case 500:
return `服务器错误(${errorCode}): ${message}\n请联系技术支持并提供以下信息:\n错误码: ${errorCode}\n时间: ${new Date().toISOString()}`;
default:
return `未知错误: ${message}`;
}
}

function formatValidationErrors(errors) {
if (!errors || errors.length === 0) return '';

return '\n具体问题:\n' + errors.map(err => `- ${err.field}: ${err.message}`).join('\n');
}

📚 参考资源

API参考文档

完整的API参考文档可在以下位置获取:

社区与支持

🔮 未来规划

MCP平台的发展路线图:

1
2
3
4
5
6
7
8
9
10
11
12
gantt
title MCP平台发展路线图
dateFormat YYYY-MM
section 核心功能
多云管理支持 :done, 2023-01, 2023-03
容器编排增强 :done, 2023-04, 2023-06
边缘计算支持 :active, 2023-07, 2023-09
AI/ML服务集成 :2023-10, 2024-01
section 安全增强
零信任架构 :done, 2023-01, 2023-05
高级威胁防护 :active, 2023-06, 2023-09
合规认证扩展 :2023-10, 2024-02
